Specification unit: mm & inch
 |
Model | P.R. | External Diameter mm |
Max. Wide mm |
Hub Wide mm |
Max. Pressure p.s.l. |
Max. Load Capacity kgf |
| 500 - 8 | 8 | 468 | 134 | 89 | 100 | 780 | |
| 250 - 15 | 20 | 742 | 230 | 191 | 150 | 3820 | |
| 300 -15 | 20 | 832 | 302 | 203 | 138 | 5216 | |
| 825-15 | 12 | 855 | 242 | 165 | 100 | 4245 | |
| 14 | 855 | 242 | 165 | 114 | 4590 | ||
| 1000 - 15 | 16 | 910 | 273 | 178 | 120 | 6856 | |
| 28 x 9 - 15 | 12 | 570 | 225 | 165 | 145 | 2650 | |
| 650 - 10 | 10 | 600 | 180 | 127 | 100 | 1385 | |
| 750 - 10 | 12 | 645 | 195 | 127 | 120 | 2565 | |
| 700 - 12 | 12 | 680 | 187 | 127 | 125 | 2718 | |
| 750 -15 | 12 | 785 | 217 | 153 | 116 | 4000 | |
| 28 x 12.5-15 | 20 | 0 | 0 | 0 | 0 | 0 | |
| 750 - 16 | 12 | 0 | 0 | 0 | 0 | 0 | |
| 700 - 15 | 12 | 0 | 0 | 0 | 0 | 0 | |
| 600 - 15 | 10 | 0 | 0 | 0 | 0 | 0 | |
| 550 - 15 | 8 | 0 | 0 | 0 | 0 | 0 | |
| 825 - 12 | 12 | 0 | 0 | 0 | 0 | 0 | |
| 600 - 6 | 10 | 0 | 0 | 0 | 0 | 0 |
 |
 |
 |
¡@
